LED & Light

▶ Faro

876687 - LED-OPB-ZW-NW

Package type: CT á 1 PCE

Faro XPG LED opbouw armatuur, Zwart, 2.1W, 700mA, 4000K

Product specifications : 876687 - LED-OPB-ZW-NW

Spot
Mounting method
Surface mounting
Dimmable
Yes
Colour temperature (K)
4000 - 4000
Colour of light adjustable
No
Rated luminous flux according to IEC 62722-2-1 (lm)
215
(lm)
0 - 215
(lm/W)
0 - 102
Nominal current (mA)
0 - 700
Nominal voltage (V)
3 - 3
Voltage type
DC
Max. system power (W)
2.1
Energy efficiency class of the light source according to EU regulation 2019/2015
E
Beam angle
Medium beam 21-40°
Beam angle (°)
35
Width (mm)
32
Height/depth (mm)
37
Outer diameter (mm)
19
Housing colour
Black
Degree of protection (IP), front side
IP44
Other
Degree of protection (IP)
IP20
Suitable for ceiling mounting
Yes
Suitable for wall mounting
Yes
Luminous flux adjustable
Continuously variable
Suitable for lamp power (W)
2.1 - 2.1
Adjustability
Swivelling
Lamp type
LED not exchangeable
With light source
Yes
Electrical connection with connector system
Yes
Type of control gear
LED operating device current-controlled
With control gear
No
Colour of light
White
Housing material
Aluminium
Moulded-on
Light sharing
Symmetric
Colour rendering index CRI
80-89
Suitable for surface mounting
Yes
Suitable for built-in mounting
No
Optics
Lens
(cm)
100
Light distributor
Focal lens
Light outlet
Direct
Number of poles
2
With mounting bracket
Yes
With presence indicator
No

Variants

863680 - LCB-OPB-NW
4000 - 4000
10 - 320
320
0 - 320
0 - 103
0 - 350
8.8 - 8.8
3.1
E
40
36
45
32
Aluminium
IP44
3.1 - 3.1
Reflector
Reflector
863681 - LCB-OPB-EWW
2700 - 2700
10 - 320
320
0 - 320
0 - 103
0 - 350
8.8 - 8.8
3.1
E
40
36
45
32
Aluminium
IP44
3.1 - 3.1
Reflector
Reflector
863682 - LCB-OPB-WW
3000 - 3000
10 - 320
320
0 - 320
0 - 103
0 - 350
8.8 - 8.8
3.1
E
40
36
45
32
Aluminium
IP44
3.1 - 3.1
Reflector
Reflector
863685 - LCB-OPB-ZW-EWW
2700 - 2700
10 - 320
320
0 - 320
0 - 103
0 - 350
8.8 - 8.8
3.1
E
40
36
45
32
Black
IP44
3.1 - 3.1
Reflector
Reflector
863686 - LCB-OPB-ZW-WW
3000 - 3000
0 - 458
458
0 - 458
0 - 148
0 - 350
8.8 - 8.8
3.1
C
40
27
45
32
Black
IP44
3.1 - 3.1
Lens
Focal lens
863687 - LCB-OPB-ZW-NW
4000 - 4000
10 - 320
320
0 - 320
0 - 103
0 - 350
8.8 - 8.8
3.1
E
40
36
45
32
Black
IP44
3.1 - 3.1
Reflector
Reflector
876680 - LED-OPB-NW
4000 - 4000
215
0 - 215
0 - 102
0 - 700
3 - 3
2.1
E
35
32
37
19
Aluminium
IP20
2.1 - 2.1
Lens
Focal lens
876681 - LED-OPB-EWW
2700 - 2700
215
0 - 215
0 - 102
0 - 700
3 - 3
2.1
E
35
32
37
19
Aluminium
IP44
2.1 - 2.1
Lens
Focal lens
876682 - LED-OPB-WW
3000 - 3000
215
0 - 215
0 - 102
0 - 700
3 - 3
2.1
E
35
32
37
19
Aluminium
IP44
2.1 - 2.1
Lens
Focal lens
876684 - LED-OPB-CW
6000 - 6000
215
0 - 215
0 - 102
0 - 700
3 - 3
2.1
E
35
32
37
19
Aluminium
IP20
2.1 - 2.1
Lens
Focal lens
