▶ Parallel Connector

220013 - P-150

Package type: BX á 25 PCE

Ongeïsol. parallelverbinder, 150 mm2

Product specifications : 220013 - P-150

Nominal cross section (mm²)
150 - 150
Min. AWG-size
250 kcmil
Max. AWG-size
250 kcmil
Model
UL model
Sleeve form
Short
Suitable for solid conductors
Yes
Suitable for stranded conductors
Yes
Suitable for fine strand conductors
Yes
Suitable for high temperatures (to 650 °C)
No
Suitable for insulated varnish
No
Suitable for round conductors
Yes
Suitable for flat conductors
No
Material
Copper
Surface protection
Tinned
Insulation
None
Voltage level
Up to 600 V
Type of connection
Parallel connector
Number of branches
0
For pull protected connections
No
Oil stop/centre bar
No
Nominal current (A)
405
(mm)
27
(mm)
19.5
(mm)
26.4
No

Variants

220001 - P-2216
0.34 - 1.65
22
16
18
8
1.7
3.3
220002 - P-1614
1.04 - 2.63
18
14
30
8
2.3
3.9
220003 - P-1210
2.63 - 6.64
14
10
50
8.5
3.5
5.4
220004 - P-8
10 - 10
8
8
70
9.5
4.5
7
220005 - P-14
16 - 16
6
6
95
11
5.8
8.9
220006 - P-22
25 - 25
4
4
125
13.5
7.7
11.3
220007 - P-38
35 - 35
2
2
170
16.5
9.4
13.2
220008 - P-50
50 - 50
1
1
230
19
11.4
15.3
220009 - P-70
70 - 70
00
00
265
19
13.3
17.5
220011 - P-95
95 - 95
000
000
310
19.5
15.5
19.5
