Siena

863720 - LCB-SPOT-62RB-WW

Package type: CT á 1 PCE

Siena COB richtbare ledspot, RVS look, 3,1W, 350mA, 3000K

Product specifications : 863720 - LCB-SPOT-62RB-WW

Spot
Mounting method
Built-in
Colour temperature (K)
3000 - 3000
Colour of light adjustable
No
Nominal current (mA)
0 - 350
Nominal voltage (V)
8.8 - 8.8
Voltage type
DC
Max. system power (W)
3.1
Energy efficiency class of the light source according to EU regulation 2019/2015
E
Beam angle
Medium beam 21-40°
Beam angle (°)
40
Built-in depth (mm)
27
Height/depth (mm)
27
Outer diameter (mm)
62
Built-in diameter (mm)
50 - 50
Housing colour
Stainless steel
Degree of protection (IP), front side
IP44
Other
Suitable for ceiling mounting
Yes
Luminous flux adjustable
Continuously variable
Suitable for lamp power (W)
3.1 - 3.1
Suitable for clamp-mounting
Yes
Adjustability
Rotating and swivelling
Lamp type
LED not exchangeable
With light source
Yes
Electrical connection with connector system
Yes
Type of control gear
LED operating device current-controlled
With control gear
No
Colour of light
White
Housing material
Aluminium
Light sharing
Symmetric
Colour rendering index CRI
80-89
Suitable for surface mounting
No
Suitable for built-in mounting
Yes
Optics
Reflector
(cm)
100
Light distributor
Reflector
Light outlet
Direct
Number of poles
2
Colour consistency (McAdam ellipse)
SDCM1
Exchangeable control gear
Yes
Beam angle adjustable
No
With mounting bracket
No
With presence indicator
No
Dimmable
Yes

Variants

863702 - LCB-SPOT-62RB-EWW-RVS
2700 - 2700
50 - 60
Stainless steel
IP55
Stainless steel
863704 - LCB-SPOT-62RB-WW-RVS
3000 - 3000
50 - 60
Stainless steel
IP55
Stainless steel
863710 - LCB-SPOT-62RB-EWW-WH
2700 - 2700
50 - 60
White
IP44
Aluminium
863712 - LCB-SPOT-62RB-WW-WH
3000 - 3000
50 - 60
White
IP44
Aluminium
863714 - LCB-SPOT-62RB-NW-WH
4000 - 4000
50 - 60
White
IP44
Aluminium
863716 - LCB-SPOT-62R-WW-ZW
3000 - 3000
50 - 60
Black
IP44
Aluminium
863718 - LCB-SPOT-62R-EWW-ZW
2700 - 2700
50 - 60
Black
IP44
Aluminium
863719 - LCB-SPOT-62RB-NW-ZW
4000 - 4000
50 - 60
Black
IP44
Aluminium
863721 - LCB-SPOT-62R-EWW
2700 - 2700
50 - 50
Stainless steel
IP44
Aluminium
