LED & Light

▶ Bonvino, 7W, Lens

868512 - LED-7W-LS30-EWW

Package type: CT á 1 PCE

Bonvino LED module, 6.6W, 700mA, 650 lumen, 2700K, 30° lens

Product specifications : 868512 - LED-7W-LS30-EWW

Spot
Housing colour
White
Shape
Round
Operating current (mA)
0 - 700
Voltage type
DC
Lamp voltage (V)
9.4 - 9.4
Luminous flux (lm)
0 - 650
(lm)
0 - 650
Suitable for constant voltage
No
Suitable for constant current
Yes
External driver required
Yes
Colour temperature (K)
2700 - 2700
Number of LEDs
1
Colour
White
Connection type
Other
(cm)
100
Optics
Lens
Diameter (mm)
48
Length (mm)
48
Width (mm)
48
Height (mm)
63
Built-in diameter (mm)
48
Degree of protection (IP)
IP20
(mm)
44
Energy efficiency class according to EU regulation 2019/2015
F
Beam angle (°)
30 - 30
Lamp power (W)
6.6 - 6.6
Dimmable
Yes
Average nominal lifespan (h)
50000
Colour of light according to EN 12464-1
Warm white <3300 K
Colour rendering index CRI
80-89
Colour consistency (McAdam ellipse)
SDCM1
Specific luminous efficacy (lm/W)
0 - 98
Operating voltage (V)
9.4 - 9.4
IFTTT support available
No
Suitable for matrix information boards
No
Suitable for traffic lights
No
Suitable for rail traffic
No
Suitable for general lighting
Yes
Suitable for variable road signs
No

Variants

868511 - LED-7W-LS30-DTW
0 - 350
19 - 19
0 - 620
0 - 620
1800 - 3000
Warm white <3300 K
0 - 93
19 - 19
868514 - LED-7W-LS30-WW
0 - 700
9.4 - 9.4
0 - 650
0 - 650
3000 - 3000
Warm white <3300 K
0 - 98
9.4 - 9.4
868516 - LED-7W-LS30-NW
0 - 700
9.4 - 9.4
0 - 650
0 - 650
4000 - 4000
Neutral white 3300-5300 K
0 - 98
9.4 - 9.4
