Lighting Controls

▶ Surface mounted

840005 - LIGHTGUARD

Package type: CT á 1 PCE

Product specifications
Downloads

Product specifications : 840005 - LIGHTGUARD

Model

Surface mounting

Type of sensor

Built-in light sensor

Mounting method

Surface mounted (plaster)

Relay

Colour

Grey

Engaging brightness (lx)

5 - 10000

Switching-off brightness (lx)

10 - 20000

Yes

Switch-off delay (s)

Switching-on delay (s)

Contacts

1 make contact (NO)

Max. switching power (W)

2000

Max. switching power LED (W)

2000

Max. switching current (resistive load) (A)

8.7

(W)

1 - 2000

(W)

0.5

Suitable for C-load

Yes

With automatic night switch-off

Material

Plastic

Surface protection

Untreated

Surface finishing

Matt

Nominal voltage (V)

230

Voltage type

Operating temperature (°C)

-25 - +45

Suitable for degree of protection (IP)

IP55

Width (mm)

Height (mm)

Depth (mm)

Swivelling

With DALI interface

Compatible with Amazon Alexa

Compatible with Google Assistant

Compatible with Apple HomeKit

IFTTT support available

Transparent

Variants

840000 - LIGHTCON

▶Colour: White
▶Engaging brightness (lx): 5 - 1000
▶Switching-off brightness (lx): 5 - 5
▶Switch-off delay (s): 60
▶Switching-on delay (s): 60
▶Max. switching power (W): 1000
▶Max. switching power LED (W): 400
▶ (W): 1 - 400
▶ (VA): 1 - 900
▶Max. switching current (resistive load) (A): 10
▶ (W): 1 - 1000
▶With automatic night switch-off: No
▶Nominal voltage (V): 230
▶Voltage type: AC
▶Operating temperature (°C): -20 - +50
▶Suitable for degree of protection (IP): IP55
▶Length (mm): 95
▶Width (mm): 74
▶Height (mm): 45

840007 - LIGHTGUARD/KL

▶Colour: Grey
▶Engaging brightness (lx): 5 - 300
▶Switching-off brightness (lx): 10 - 600
▶Switch-off delay (s): 60
▶Switching-on delay (s): 60
▶Max. switching power (W): 2300
▶Max. switching power LED (W): 400
▶ (W): 1 - 1500
▶ (VA): 1 - 120
▶Max. switching current (resistive load) (A): 10
▶ (W): 1 - 2300
▶With automatic night switch-off: Yes
▶Nominal voltage (V): 230
▶Voltage type: AC
▶Suitable for degree of protection (IP): IP54
▶Length (mm): 95
▶Width (mm): 80
▶Height (mm): 42

840010 - EUROSWITCH

▶Colour: Grey
▶Engaging brightness (lx): 5 - 10000
▶Switching-off brightness (lx): 20 - 20000
▶Switch-off delay (s): 180
▶Switching-on delay (s): 180
▶Max. switching power (W): 3800
▶Max. switching power LED (W): 1500
▶ (W): 1 - 40
▶ (VA): 1 - 120
▶Max. switching current (resistive load) (A): 16
▶ (W): 1 - 3800
▶With automatic night switch-off: No
▶Nominal voltage (V): 230
▶Voltage type: AC
▶Suitable for degree of protection (IP): IP55
▶Length (mm): 95
▶Width (mm): 74
▶Height (mm): 45

840012 - EUROSW-12VDC

▶Colour: Grey
▶Engaging brightness (lx): 1 - 300
▶Switching-off brightness (lx): 5 - 600
▶Switch-off delay (s): 180
▶Switching-on delay (s): 180
▶Max. switching power (W): 120
▶Max. switching power LED (W): 40
▶ (W): 1 - 50
▶ (VA): 1 - 150
▶Max. switching current (resistive load) (A): 10
▶ (W): 1 - 120
▶With automatic night switch-off: No
▶Nominal voltage (V): 12
▶Voltage type: DC
▶Suitable for degree of protection (IP): IP55
▶Length (mm): 95
▶Width (mm): 74
▶Height (mm): 45

840013 - EUROSW-12VAC

▶Colour: Grey
▶Engaging brightness (lx): 1 - 300
▶Switching-off brightness (lx): 5 - 600
▶Switch-off delay (s): 180
▶Switching-on delay (s): 180
▶Max. switching power (W): 150
▶Max. switching power LED (W): 50
▶ (W): 1 - 60
▶ (VA): 1 - 150
▶Max. switching current (resistive load) (A): 16
▶ (W): 1 - 150
▶With automatic night switch-off: No
▶Nominal voltage (V): 12
▶Voltage type: AC
▶Suitable for degree of protection (IP): IP55
▶Length (mm): 95
▶Width (mm): 74
▶Height (mm): 45

840015 - EUROSW-24VDC

▶Colour: Grey
▶Engaging brightness (lx): 1 - 300
▶Switching-off brightness (lx): 5 - 600
▶Switch-off delay (s): 180
▶Switching-on delay (s): 180
▶Max. switching power (W): 240
▶Max. switching power LED (W): 60
▶ (W): 1 - 100
▶ (VA): 1 - 1000
▶Max. switching current (resistive load) (A): 10
▶ (W): 1 - 240
▶With automatic night switch-off: No
▶Nominal voltage (V): 24
▶Voltage type: DC
▶Suitable for degree of protection (IP): IP55
▶Length (mm): 95
▶Width (mm): 74
▶Height (mm): 45

840016 - EUROSW-24VAC

▶Colour: Grey
▶Engaging brightness (lx): 1 - 300
▶Switching-off brightness (lx): 5 - 600
▶Switch-off delay (s): 180
▶Switching-on delay (s): 180
▶Max. switching power (W): 300
▶Max. switching power LED (W): 100
▶ (W): 1 - 500
▶ (VA): 1 - 1000
▶Max. switching current (resistive load) (A): 16
▶ (W): 1 - 300
▶With automatic night switch-off: No
▶Nominal voltage (V): 24
▶Voltage type: AC
▶Suitable for degree of protection (IP): IP55
▶Length (mm): 95
▶Width (mm): 74
▶Height (mm): 45

840020 - EUROSWITCH-110V

▶Colour: Grey
▶Engaging brightness (lx): 1 - 300
▶Switching-off brightness (lx): 5 - 600
▶Switch-off delay (s): 180
▶Switching-on delay (s): 180
▶Max. switching power (W): 1500
▶Max. switching power LED (W): 500
▶ (W): 1 - 600
▶Max. switching current (resistive load) (A): 16
▶ (W): 1 - 1500
▶With automatic night switch-off: No
▶Nominal voltage (V): 110
▶Voltage type: AC
▶Suitable for degree of protection (IP): IP55
▶Length (mm): 95
▶Width (mm): 74
▶Height (mm): 45

840030 - EUROSWITCH-130V

▶Colour: Grey
▶Engaging brightness (lx): 1 - 300
▶Switching-off brightness (lx): 5 - 600
▶Switch-off delay (s): 180
▶Switching-on delay (s): 180
▶Max. switching power (W): 1700
▶Max. switching power LED (W): 60
▶Max. switching current (resistive load) (A): 16
▶ (W): 1 - 1700
▶With automatic night switch-off: No
▶Nominal voltage (V): 130
▶Voltage type: AC
▶Suitable for degree of protection (IP): IP55
▶Width (mm): 74
▶Height (mm): 45
